The unDUSB is a small, cost-effective interface that bridges host
USB devices, like computers, directly to a Dante network - while
keeping the audio signals in the digital domain. The unDUSB
enumerates on USB as a standard stereo sound card, and
provides 2 channels from Dante to USB, and 2 channels from
USB to Dante. Since the unDUSB uses USB audio drivers that are
built-in to Windows and OSX, no additional drivers need to be
installed. Using an unDUSB, any computer program that can
make use of a stereo sound card can instantly have input and
output access to audio signals on a Dante network. Music,
presentation audio, and even audio from collaboration
applications like Skype can be used in a Dante system. The
unDUSB can be powered by compliant 802.3af PoE devices, from
+9VDC to +24VDC external supplies, or from the Power Link
Output connector of other Attero Tech devices that support
Power Link.
SPECIFICATIONS
Power LED: Indicates the unit is powered on.
Sys LED: Indicates that the unit is initializing (Red) or ready for
use (Green)
Sync LED: Indicates that the unit is synchronized with the Dante
network (Green), in the process of synchronizing (Amber), or unable to synchronize (Red)
Error LED: Indicates that the Dante capabilities information
stored on the unDUSB is corrupted (Yellow). Red indicates an internal firmware error.
USB Connector: Type B
USB Audio Connectivity: USB Audio 1.1, compatible with Windows 7, 8, 10, OSX V10.7 or newer
Audio Channels: 2 channel from USB to the Dante network, and 2
channel from the Dante network to USB
Digital Audio Sample Rates/Bit Depth: 44.1/48kHz sample rates
are supported on the USB input, and 48kHz sample rate on the
Dante input. Bit depth is 16 bits, with full asynchronous sample
rate conversion between USB and the Dante network
Frequency Response: 20Hz - 20kHz, +/-1dB
PoE Class: Class 0 802.3af PoE PD compliant
Certifications: FCC 47CFR Parts 15B and 18 (Class A), EN 55011,
ICES-003, CE (EN55022 Class A and EN55024 Class A)
Power Consumption: < 4W
Dimensions: 6.45” W x 1.06” H x 3.45” D
Operating Temperature: 0°C ‐ 40°C
